DC MOTOR SELECTION - GEARED
HOME
Tech Note
Most DC motors are normally very easy to reverse, simply changing the polarity of the DC input will reverse the direction of the drive shaft. This changeover process can be achieved via a simple changeover switch or for remote or electronic control, via a suitable relay. When using a switch or relay always check the contact current ratings and allow for larger currents to be switched, as different mechanical loads and instant reverse can draw much higher currents than when the motor is being run unloaded. Another big advantage of DC motors is that variable speed control is easy and can achieved with just a suitable variable resistor / rheostat or variable DC power supply. For more precise control and maximum efficiency there are many other electronic PWM (pulse width modulation) solutions, although these tend to have added complexity. Most DC motors are designed to exhibit the same speed and output torque in either the forward or reverse direction. Drive shaft speeds rpm (Revs Per Minute) are quoted with motor unloaded.
12 V DC 520 rpm
* Sold Out *
12 V DC 152 rpm
12 V DC 162 rpm with encoder
FX54
12 V DC 330 rpm
12 V DC 33 rpm
12 V DC 1500 rpm
12 V DC 40 rpm - Very small !!
6 to 24 V DC 125 / 790 rpm TS52
6 to 24 V DC 30 / 140 rpm
TS53
